MOTOR CONTROL 400V EASYWASH365+

Product No.: 920001380

For the operation of motors with 4 - 7.5 kW power at 400 VAC, 50 Hz

Dimensions H x W x D: 380 x 380 x 210 mm, IP 65, equipped with

Supply: 400VAC, 50Hz, 3Ph / N / PE with main switch (cam switch) 25A
Control voltage conditioning24VDC, 2.5A with backup fuse 2A
Motor outlet with power contactor 7.5kW and wide-range motor protection switch 8-32A
LOGO small control unit
1 operating hours counter (IP 65) and 2 command and signaling devices in the door
Optional operation with 2 pressure switches or 1 flow switch or without control function
Protection class: IP 65
Sheet steel wall housing
RAL7035 powder-coated
Weight: 14.0 kg
